Packaging | Bulk | |
Type | Isolated Module | |
Number of Outputs | 2 | |
Voltage - Input (Min) | 18V | |
Voltage - Input (Max) | 75V | |
Voltage - Output 1 | 5V | |
Voltage - Output 2 | -5V | |
Voltage - Output 3 | - | |
Current - Output (Max) | 2A, 2A | |
Power (Watts) - Manufacture Series | 20W | |
Voltage - Isolation | 1.5kV (1500V) | |
Features | With Remote On/Off and UVLO | |
Mounting Type | Through Hole | |
Package / Case | 6-DIP Module | |
Size / Dimension | 2.00" L x 1.18" W x 0.89" H (50.8mm x 30.0mm x 22.5mm) | |
Operating Temperature | -40°C ~ 85°C | |
Efficiency | 85% | |
Power (Watts) - Max | 20W | |
Other Names | 102-2580 VYB20WQ48D5H | |
