Packaging | Tape & Reel (TR) | |
Type | Linear Regulator Replacement | |
Number of Outputs | 1 | |
Voltage - Input (Min) | 14V | |
Voltage - Input (Max) | 28V | |
Voltage - Output 1 | 12V | |
Voltage - Output 2 | - | |
Voltage - Output 3 | - | |
Current - Output (Max) | 500mA | |
Power (Watts) - Manufacture Series | 6W | |
Voltage - Isolation | - | |
Features | Remote On/Off, OTP, SCP | |
Mounting Type | Surface Mount | |
Package / Case | 10-SMD Module (6 Leads) | |
Size / Dimension | 0.60" L x 0.34" W x 0.28" H (15.2mm x 8.6mm x 7.1mm) | |
Operating Temperature | -40°C ~ 85°C | |
Efficiency | 95% | |
Power (Watts) - Max | 6W | |
Other Names | 102-1959-2 V7812-500-SMT V7812500SMTTR | |
