R87F-A4A15HP

View larger image

Part Number

R87F-A4A15HP

Manufacturer

Description
FAN AXIAL 120X38MM 200VAC TERM
Category
Fans, Thermal Management
Family
AC Fans
  • To learn about the specification of R87F-A4A15HP, please search the datasheet by clicking the link above. If you couldn't find the correct datasheet, please refer to the manufacturer's official datasheet.
  • To process your RFQ, please add R87F-A4A15HP with quantity into BOM.
  • Omoelec.com does NOT require any registration to request a quote of R87F-A4A15HP.
  • We are offering R87F-A4A15HP for competitive price in the global market, please send us a quote request for pricing. Thank you!
Quick Order
Specifications of R87F-A4A15HP
Voltage - Rated200VAC
Size / DimensionSquare - 120mm L x 120mm H x 38mm W
Width*
Air Flow95.3 CFM (2.70m³/min)
Static Pressure0.374 in H2O (93.1 Pa)
Bearing TypeBall
Fan TypeTubeaxial
Features-
Noise42 dB
Power (Watts)15.0W
RPM2750 RPM
Termination2 Terminals
Ingress Protection-
Operating Temperature-22 ~ 158°F (-30 ~ 70°C)
ApprovalsCE, CSA, UL
Weight1.2 lbs (544.3g)
Current Rating0.100A
Voltage Range-
Material - FrameAluminum
Material - BladePolycarbonate (PC)
Other NamesR87F-A4A15HP-ND
R87FA4A15HP
Z3716
