- Part Number
PS5N
- Manufacturer
NKK Switches
- Description
- SWITCH ROTARY SP 30A NONSHORT
- Category
- Switches
- Family
- Rotary Switches
- To learn about the specification of PS5N, please search the datasheet by clicking the link above. If you couldn't find the correct datasheet, please refer to the manufacturer's official datasheet.
- To process your RFQ, please add PS5N with quantity into BOM.
- Omoelec.com does NOT require any registration to request a quote of PS5N.
- We are offering PS5N for competitive price in the global market, please send us a quote request for pricing. Thank you!
Quick Order
Specifications of PS5N
| Number of Positions | 2 ~ 11 | |
| Index Stops | Adjustable | |
| Number of Decks | 5 | |
| Number of Poles per Deck | 1 | |
| Circuit per Deck | SP11T | |
| Contact Timing | Non-Shorting (BBM) | |
| Current Rating | 30A (AC) | |
| Voltage Rating - AC | 125V | |
| Voltage Rating - DC | - | |
| Actuator Type | Flatted (6mm Dia) | |
| Actuator Length | 15.00mm | |
| Angle of Throw | 30° | |
| Contact Material | Silver Alloy | |
| Contact Finish | - | |
| Mounting Type | Panel Mount | |
| Termination Style | Screw Terminal | |
| Features | - | |
| Depth Behind Panel | 116.50mm | |
| Panel Cutout Dimensions | Circular - 10.50mm Dia | |
| Operating Force, Torque | 0.70 N-m | |
| Other Names | PS5N-RO PS5N-RO-ND | |
| call me | [email protected] | |
