Part Number

PHE426HD7100JR06L2

Manufacturer

Description
CAP FILM 1UF 5% 250VDC RADIAL
Category
Capacitors
Family
Film Capacitors

  • To learn about the specification of PHE426HD7100JR06L2, please search the datasheet by clicking the link above. If you couldn't find the correct datasheet, please refer to the manufacturer's official datasheet.
  • To process your RFQ, please add PHE426HD7100JR06L2 with quantity into BOM.
  • Omoelec.com does NOT require any registration to request a quote of PHE426HD7100JR06L2.
  • We are offering PHE426HD7100JR06L2 for competitive price in the global market, please send us a quote request for pricing. Thank you!
Quick Order
Specifications of PHE426HD7100JR06L2
PackagingBulk
Capacitance1µF
Tolerance±5%
Voltage Rating - AC160V
Voltage Rating - DC250V
Dielectric MaterialPolypropylene (PP), Metallized
ESR (Equivalent Series Resistance)-
Operating Temperature-55°C ~ 105°C
Mounting TypeThrough Hole
Package / CaseRadial
Size / Dimension1.024" L x 0.276" W (26.00mm x 7.00mm)
Height - Seated (Max)0.650" (16.50mm)
TerminationPC Pins
Lead Spacing0.886" (22.50mm)
ApplicationsHigh Pulse, DV/DT
Features-
Other Names399-5961
F426DF105J250C
