- Part Number
PF0553.822NLT
- Manufacturer
Pulse Electronics Corporation
- Description
- INDUCT ARRAY 2 COIL 8.9UH SMD
- Category
- Inductors, Coils, Chokes
- Family
- Arrays, Signal Transformers
- To learn about the specification of PF0553.822NLT, please search the datasheet by clicking the link above. If you couldn't find the correct datasheet, please refer to the manufacturer's official datasheet.
- To process your RFQ, please add PF0553.822NLT with quantity into BOM.
- Omoelec.com does NOT require any registration to request a quote of PF0553.822NLT.
- We are offering PF0553.822NLT for competitive price in the global market, please send us a quote request for pricing. Thank you!
Quick Order
Specifications of PF0553.822NLT
| Packaging | Tape & Reel (TR) | |
| Number of Coils | 2 | |
| Inductance - Connected In Series | 35µH | |
| Inductance - Connected In Parallel | 8.9µH | |
| Tolerance | ±20% | |
| Current Rating - Parallel | 6.2A | |
| Current Rating - Series | 3.1A | |
| Current Saturation - Parallel | 12A | |
| Current Saturation - Series | 6.1A | |
| DC Resistance (DCR) - Parallel | 15 mOhm Max | |
| DC Resistance (DCR) - Series | 62 mOhm Max | |
| Shielding | Shielded | |
| Operating Temperature | -40°C ~ 125°C | |
| Mounting Type | Surface Mount | |
| Package / Case | Nonstandard | |
| Size / Dimension | 0.492" L x 0.492" W (12.50mm x 12.50mm) | |
| Height | 0.315" (8.00mm) | |
| call me | [email protected] | |
