- Part Number
MX34016UF1
- Manufacturer
JAE Electronics
- Description
- CONN HEADER 16POS VERT 2.2MM TIN
- Category
- Connectors, Interconnects
- Family
- Rectangular Connectors - Headers, Male Pins
- To learn about the specification of MX34016UF1, please search the datasheet by clicking the link above. If you couldn't find the correct datasheet, please refer to the manufacturer's official datasheet.
- To process your RFQ, please add MX34016UF1 with quantity into BOM.
- Omoelec.com does NOT require any registration to request a quote of MX34016UF1.
- We are offering MX34016UF1 for competitive price in the global market, please send us a quote request for pricing. Thank you!
Quick Order
Specifications of MX34016UF1
| Packaging | Tube | |
| Contact Type | Male Pin | |
| Connector Type | Header, Shrouded | |
| Number of Positions | 16 | |
| Number of Positions Loaded | All | |
| Pitch | 0.087" (2.20mm) | |
| Number of Rows | 2 | |
| Row Spacing | 0.118" (3.00mm) | |
| Contact Mating Length | 0.303" (7.70mm) | |
| Mounting Type | Through Hole | |
| Termination | Solder | |
| Fastening Type | Locking Ramp | |
| Features | Board Guide, Mounting Flange | |
| Contact Finish | Tin | |
| Contact Finish Thickness | - | |
| Color | Gray | |
| Other Names | 670-2292 | |
| call me | [email protected] | |
