- Part Number
KC15B02NPFB31.5MM
- Manufacturer
E-Switch
- Description
- SWITCH ROTARY
- Category
- Switches
- Family
- Rotary Switches
- To learn about the specification of KC15B02NPFB31.5MM, please search the datasheet by clicking the link above. If you couldn't find the correct datasheet, please refer to the manufacturer's official datasheet.
- To process your RFQ, please add KC15B02NPFB31.5MM with quantity into BOM.
- Omoelec.com does NOT require any registration to request a quote of KC15B02NPFB31.5MM.
- We are offering KC15B02NPFB31.5MM for competitive price in the global market, please send us a quote request for pricing. Thank you!
Quick Order
Specifications of KC15B02NPFB31.5MM
| Number of Positions | 5 | |
| Index Stops | Fixed | |
| Number of Decks | 1 | |
| Number of Poles per Deck | 1 | |
| Circuit per Deck | SP5T | |
| Contact Timing | Non-Shorting (BBM) | |
| Current Rating | 350mA (AC) | |
| Voltage Rating - AC | 125V | |
| Voltage Rating - DC | - | |
| Actuator Type | Round (6mm Dia), Slotted | |
| Actuator Length | 23.50mm | |
| Angle of Throw | 30° | |
| Contact Material | Copper Alloy | |
| Contact Finish | Gold | |
| Mounting Type | Panel Mount, Through Hole | |
| Termination Style | PC Pin | |
| Features | - | |
| Depth Behind Panel | 14.10mm | |
| Panel Cutout Dimensions | Circular - 10.20mm Dia | |
| Operating Force, Torque | 800 g-cm | |
| call me | [email protected] | |
