- Part Number
JW0-0013NL
- Manufacturer
Pulse Electronics Corporation
- Description
- CONN MAGJACK 3PORT 1000 BASE-TX
- Category
- Connectors, Interconnects
- Family
- Modular Connectors - Jacks With Magnetics
- To learn about the specification of JW0-0013NL, please search the datasheet by clicking the link above. If you couldn't find the correct datasheet, please refer to the manufacturer's official datasheet.
- To process your RFQ, please add JW0-0013NL with quantity into BOM.
- Omoelec.com does NOT require any registration to request a quote of JW0-0013NL.
- We are offering JW0-0013NL for competitive price in the global market, please send us a quote request for pricing. Thank you!
Quick Order
Specifications of JW0-0013NL
| Packaging | Tray | |
| Connector Type | RJ45 with USB A, Dual | |
| Number of Ports | 3 | |
| Number of Rows | 3 | |
| Applications | 10/100/1000 Base-TX, AutoMDIX | |
| Mounting Type | Through Hole | |
| Orientation | 90° Angle (Right) | |
| Termination | Solder | |
| Height Above Board | 1.220" (31.00mm) | |
| LED Color | Green - Orange, Yellow | |
| Number of Cores per Jack | 8 | |
| Shielding | Shielded | |
| Features | Board Lock | |
| Tab Direction | Up | |
| Contact Material | Phosphor Bronze | |
| Contact Finish | Gold | |
| Contact Finish Thickness | 15µin (0.38µm) | |
| Shield Material | Brass | |
| Housing Material | Thermoplastic | |
| Operating Temperature | 0°C ~ 70°C | |
| Other Names | 553-1720 JW0-0013NL-ND JW00013NL | |
