FBK04F12H

View larger image

Part Number

FBK04F12H

Manufacturer

Description
FAN AXIAL 40X20MM 12VDC WIRE
Category
Fans, Thermal Management
Family
DC Fans
  • To learn about the specification of FBK04F12H, please search the datasheet by clicking the link above. If you couldn't find the correct datasheet, please refer to the manufacturer's official datasheet.
  • To process your RFQ, please add FBK04F12H with quantity into BOM.
  • Omoelec.com does NOT require any registration to request a quote of FBK04F12H.
  • We are offering FBK04F12H for competitive price in the global market, please send us a quote request for pricing. Thank you!
Quick Order
Specifications of FBK04F12H
Voltage - Rated12VDC
Size / DimensionSquare - 40mm L x 40mm H x 20mm W
Air Flow6.7 CFM (0.190m³/min)
Static Pressure0.260 in H2O (64.8 Pa)
Bearing TypeBall
Fan TypeTubeaxial
Features-
Noise32 dB(A)
Power (Watts)1.80W
RPM7500 RPM
Termination2 Wire Leads
Ingress Protection-
Weight0.088 lb (39.92g)
Operating Temperature14 ~ 158°F (-10 ~ 70°C)
Current Rating0.150A
Voltage Range7 ~ 13.8VDC
Life Expectancy-
Material - FramePlastic
Material - BladePlastic
Other NamesFBK 04F12H
FBK-04F12H
P9703
