B64290L44X830

To learn about the specification of B64290L44X830, please search the datasheet by clicking the link above. If you couldn't find the correct datasheet, please refer to the manufacturer's official datasheet.
To process your RFQ, please add B64290L44X830 with quantity into BOM.
Omoelec.com does NOT require any registration to request a quote of B64290L44X830.
We are offering B64290L44X830 for competitive price in the global market, please send us a quote request for pricing. Thank you!

Quick Order

Specifications of B64290L44X830

Core Type	Toroid
Inductance Factor (Al)	2.2µH
Tolerance	±25%
Gap	Ungapped
Effective Permeability (µe)	-
Initial Permeability (µi)	4300
Material	N30
Core Factor (ΣI/A) mm^-1	2.46
Effective Length (le) mm	30.09
Effective Area (Ae) mm²	12.23
Minimum Core Cross Section (Amin) mm²	-
Effective Magnetic Volume (Ve) mm³	368
Finish	Epoxy
Supplier Device Package	R 12.5 x 7.5 x 5
Height	5.95mm
Length	-
Width	-
Diameter	13.60mm
Other Names	495-3852 B64290L 44X830 B64290L0044X830
