- Part Number
AS22AV
- Manufacturer
NKK Switches
- Description
- SWITCH SLIDE DPDT 0.4VA 28V
- Category
- Switches
- Family
- Slide Switches
- To learn about the specification of AS22AV, please search the datasheet by clicking the link above. If you couldn't find the correct datasheet, please refer to the manufacturer's official datasheet.
- To process your RFQ, please add AS22AV with quantity into BOM.
- Omoelec.com does NOT require any registration to request a quote of AS22AV.
- We are offering AS22AV for competitive price in the global market, please send us a quote request for pricing. Thank you!
Quick Order
Specifications of AS22AV
| Packaging | Tray | |
| Circuit | DPDT | |
| Contact Timing | Non-Shorting (BBM) | |
| Switch Function | On-On | |
| Current Rating | 0.4VA (AC/DC) | |
| Voltage Rating - AC | 28V | |
| Voltage Rating - DC | 28V | |
| Actuator Type | Standard | |
| Actuator Length | 2.50mm | |
| Contact Material | Phosphor Bronze | |
| Contact Finish | Gold | |
| Mounting Type | Through Hole, Right Angle, Vertical | |
| Termination Style | PC Pin | |
| Features | Epoxy Sealed Terminals | |
| Actuator Material | Polyamide (PA), Nylon, Glass Filled | |
| Switch Travel | 2.50mm | |
| Operating Temperature | -30°C ~ 85°C | |
| Mechanical Life | 50,000 Cycles | |
| Electrical Life | 50,000 Cycles | |
| Operating Force | 260gf | |
| Other Names | AS22AV-RO AS22AV-RO-ND | |
