- Part Number
1393239-7
- Manufacturer
TE Connectivity Potter & Brumfield Relays
- Description
- RELAY GEN PURPOSE SPDT 12A 5V
- Category
- Relays
- Family
- Power Relays, Over 2 Amps
- To learn about the specification of 1393239-7, please search the datasheet by clicking the link above. If you couldn't find the correct datasheet, please refer to the manufacturer's official datasheet.
- To process your RFQ, please add 1393239-7 with quantity into BOM.
- Omoelec.com does NOT require any registration to request a quote of 1393239-7.
- We are offering 1393239-7 for competitive price in the global market, please send us a quote request for pricing. Thank you!
Quick Order
Specifications of 1393239-7
| Packaging | Tube | |
| Relay Type | General Purpose | |
| Coil Type | Non Latching | |
| Coil Current | 80.6mA | |
| Coil Voltage | 5VDC | |
| Contact Form | SPDT (1 Form C) | |
| Contact Rating (Current) | 12A | |
| Switching Voltage | 400VAC - Max | |
| Turn On Voltage (Max) | 3.5 VDC | |
| Turn Off Voltage (Min) | 0.5 VDC | |
| Operate Time | 8ms | |
| Release Time | 6ms | |
| Features | Insulation - Class F, Sealed - Flux Protection | |
| Mounting Type | Through Hole | |
| Termination Style | PC Pin | |
| Contact Material | Silver Nickel (AgNi) | |
| Coil Power | 403 mW | |
| Coil Resistance | 62 Ohms | |
| Operating Temperature | -40°C ~ 85°C | |
| Other Names | 1393239-7-ND 13932397 PB1682 RT114005 RT114005-ND | |
| call me | [email protected] | |
